DGSHAPE DWX-53D 5-Axis Dental Mill

Overview

The DGSHAPE DWX-53D is a high-performance 5-axis dry dental mill built for speed, stability and accuracy. A rigid machine structure, temperature compensation, enhanced spindle and expanded B-axis travel support demanding geometries and consistent results across a wide range of restorative materials.

Key Features

• High-speed 5-axis dry milling
• Rigid frame and temperature compensation improve stability
• ±35° B-axis travel for complex undercuts
• 15-station automatic tool changer
• Supports disc and pin-type workpieces
• VPanel and DGSHAPE CLOUD monitoring

Applications

Crowns, bridges, veneers, copings, implant bars, Toronto bridges, splints, surgical guides and removable dental prostheses.

Ideal For

Busy laboratories requiring a premium single-disc mill for precise, fast production of complex restorations and digital dentures.

Technical Specifications

• Milling process: Dry
• Axes: 5
• Materials: Zirconia, wax, PMMA, gypsum, PEEK, PEKK, glass-fibre reinforced resin, composite resin, CoCr sinter metal and polycarbonate
• Operating speed: X/Y up to 3,000 mm/min; Z up to 2,700 mm/min
• Spindle speed: 6,000–30,000 rpm
• Rotary travel: A ±360°; B ±35°
• Tool capacity: 15
• External dimensions: 555 × 725 × 705 mm
• Weight: 105 kg
